►2943◄74HC4051 8-Channel-Mux 8通道 模擬多路選擇器 模組

商品編號:P7349910549542 原始貨號:2943
$ 30
預計出貨天數2
數量
  • 付款方式:
    超商取貨付款
  • 運送方式:
    常溫7-ELEVEN店到店取貨付款

商品特色

74HC4051 8-Channel-Mux 8通道 類比多路選擇器 模組 74HCT4051 is a single-pole octal-throw analog switch (SP8T) suitable for use in analog or digital 8:1 multiplexer/demultiplexer applications. The switch features three digital select inputs (S0, S1 and S2), eight independent inputs/outputs (Yn), a common input/output (Z) and a digital enable input (E). When E is HIGH, the switches are turned off. Inputs include clamp diodes. This enables the use of current limiting resistors to interface inputs to voltages in excess of VCC. 2. Features and benefits Wide analog input voltage range from 5 V to +5 V Complies with JEDEC standard no. 7A Low ON resistance: 80 (typical) at VCC VEE = 4.5 V 70 (typical) at VCC VEE = 6.0 V 60 (typical) at VCC VEE = 9.0 V Logic level translation: to enable 5 V logic to communicate with 5 V analog signals Typical ‘break before make’ built-in ESD protection: HBM JESD22-A114F exceeds 2000 V MM JESD22-A115-A exceeds 200 V CDM JESD22-C101E exceeds 1000 V Multiple package options Specified from 40度C to +85度 C and 40度 C to +125度 C
