✅產品保固:12年保固
✅產品特色
★80 PLUS®金牌認證
★符合ATX 3.0 和 16 pin PCIe Gen 5線 (12VHPWR)
★12VHPWR 模組線以符合支援最新顯卡
★嚴格的電壓調節(12 V、5 V 和 3.3 V)[± 3 %]
★採用鍍金大電流端子(MB、CPU 和 PCIe)
★流體動力軸承 (FDB) 13.5公分靜音風扇,可執行最佳冷卻效率
★完整的保護功能:OPP / OVP / UVP / SCP / OCP / OTP
★12 年保固- 海韻對高品質的承諾
✅產品規格
80PLUS® Gold
Cybenetics Efficiency Level TBA
Cybenetics Noise Level TBA
Form Factor Intel ATX 12 V
Dimensions 160 mm (L) x 150 mm (W) x 86 mm (H)
Fan Information Fan Size 135 mm
Fan Control Digital Fan Control
Fan Bearing Fluid Dynamic Bearing
Life Expectancy 50,000 hours at 40 °C, 15 % - 65 % RH
Cable Information Modularity Fully Modular
Cable type White Cables with Braided Pattern
Electrical Features Operating Temperature 0 - 50 °C
MTBF @ 25 °C, excl. fan 100,000 hours
AC Input Full Range
Protection OPP, OVP, UVP, OCP, OTP, SCP
Safety and Environmental Safety and EMC cTUVus, TUV, CB, CCC, BSMI, EAC, CE
Environmental Compliance Energy Star, RoHS, WEEE, ErP Lot 6, REACH
Warranty 12 Years
AC Input Voltage: 100 V - 240 V
Current: 13 - 6.5 A
Frequency: 50 Hz - 60 Hz
DC Output Rail +3.3 V +5 V +12 V -12 V +5 VSB
Maximum Power 25 A 25 A 83 A 0.3 A 3 A
125 W 996 W 3.6 W 15 W
Total continuous power 1000 W
