✅產品保固:六年保固
✅產品規格
FAN Specification
Size 120x120x25 mm
Mounting hole spacing 105x105 mm
Connector & pin-configuration 4-pin PWM
Cable length 2cm + 30cm NA-EC1 extension cable
Bearing SSO2
Blade geometry Heptaperf™
Frame technology Focused Flow™
Rotational speed (+/- 10%) 1500 RPM
Min. rotational speed @ 20% PWM (+/-20%) 300 RPM
Airflow 93,4 m³/h
Acoustical noise 22,4 dB(A)
Static pressure 2,61 mm H₂O
Input power (typical) 0,4 W
Input power (max.) 0,6 W
Input current (typical) 0,03 A
Max. input current 0,05 A
Operating voltage 12 V
MTTF > 150.000 h
Scope of delivery
4x NA-AVP1 chromax.black anti-vibration pads
4x NA-AVP1 chromax.blue anti-vibration pads
4x NA-AVP1 chromax.green anti-vibration pads
4x NA-AVP1 chromax.red anti-vibration pads
4x NA-AVP1 chromax.white anti-vibration pads
4x NA-AVP1 chromax.yellow anti-vibration pads
NA-EC1 chromax.black 30 cm extension cable
4x fan screws
Warranty 6 years
