ASUS 華碩RT-BE92U / 3年保固
BUFFALO 巴比祿WCR-G300 / 庫存新品/無保固/無外觀保證
ASUS 華碩 RT-BE92U 是一款高效能的 WiFi 7 三頻路由器,提供高達 9700 Mbps 的總無線速度,並配備多個 2.5G 和 10G 有線連接埠,適合需要高速穩定網路的智慧家庭或小型企業。
主要規格
ASUS RT-BE92U 旨在利用最新的 WiFi 7 (802.11be) 技術提供卓越的覆蓋範圍和速度。
ASUS RT-BE92U 符合 IEEE 802.11a/b/g/n/ac/ax/be 等網路技術標準,並支援 IPv4 和 IPv6 協定。此產品屬於 BE9700 等級,提供總計 9700 Mbps 的極致 BE 效能 (1032+2882+5764 Mbps)。其資料傳輸速率在 2.4GHz 頻段最高可達 1032 Mbps,5GHz 頻段最高可達 2882 Mbps,6GHz 頻段最高可達 5764 Mbps。該路由器配備 4 支外接天線 (2.4GHz 3x3, 5GHz 2x2, 6GHz 2x2) 及 1 支內部 2.4GHz 天線。內部硬體搭載 2.0GHz 四核心處理器、256 MB Flash 和 1 GB DDR4 RAM。I/O 連接埠包含 1 個 10Gbps WAN/LAN、1 個 2.5Gbps WAN/LAN、3 個 2.5 Gbps LAN 和 1 個 USB 3.2 Gen1。此外,它還支援 MLO 多重連接模式、320 MHz 通道、4096-QAM、AiMesh、AiProtection Pro、VPN 和家長控制等功能。
型號
ASUS RT-BE92U
網路技術標準
IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
WiFi 4 (802.11n)
WiFi 5 (802.11ac)
WiFi 6 (802.11ax)
WiFi 6E (802.11ax)
WiFi 7 (802.11be)
IPv4
IPv6
產品規格
BE9700 ultimate BE performance : 1032+2882+5764 Mbps
傳輸量
WiFi 7 (802.11be) (2.4GHz): up to 1032 Mbps
WiFi 7 (802.11be) (5GHz): up to 2882 Mbps
WiFi 7 (802.11be) (6GHz): up to 5764 Mbps
天線
External antenna x 4
傳送 / 接收
2.4GHz 3x3
5GHz 2x2
6GHz 2x2
處理器
2.0GHz quad-core processor
記憶體
256 MB Flash and 1 GB DDR4 RAM
網速提升
OFDMA (Orthogonal Frequency Division Multiple Access)
Beamforming: standard-based and universal
4096-QAM high data rate
20/40/80/160/320 MHz bandwidth
運作頻率
2.4 GHz
5 GHz
6 GHz
Operating Mode
Wireless Router Mode
AiMesh Node Mode
Access Point Mode
Media Bridge Mode
Repeater Mode
網路埠規格
1 x 10Gbps for WAN/LAN
1 x 2.5Gbps for WAN/LAN
3 x 2.5 Gbps for LAN
USB 3.2 Gen1 x1
按鈕
WPS Button, Reset Button, Power Switch
LED 指示燈
Power x1
WAN x1
LAN x1
2.4GHz x1
5GHz x1
6GHz x1
電源規格
AC Input: 110V~240V(50~60Hz)
DC Output: 12 V with max. 3 A current
包裝內容物
RT-BE92U WiFi 7 Tri-band Router
wall mount kit
RJ-45 cable
Power Adapter
Quick Start Guide
Warranty Card
Product Dimensions
247.18 x 101.59 x 287.47 mm / 9.73 x 4.00 x 11.32 inch
獨家AiMesh技術
AiMesh
Primary AiMesh router
AiMesh node
家長貼心管理
Web & Apps Filters
Time Scheduling
Safe Browsing
Parental Control Customized Internet schedule
• Maximum Parental Control Profile : 64
Guest Network
Guest Network
Support Guest Network
• Maximum Guest Network Rule : 2.4 GHz + 5 GHz : 3
Guest Network Pro Encryption : Open system, WPA/WPA2/WPA3-Personal
Security
AiProtection
VPN
WPA/WPA2/WPA3 Personal
WPA/WPA2/WPA3 Enterprise
Open System & OWE
WPS
Let's Encrypt
DNS-over-TLS
SSH
Security Scan
Firewall
• Maximum Firewall Keyword Filter : 64
• Maximum Firewall Network Service Filter : 32
• Maximum Firewall URL Filter : 64
AiProtection
AiProtection
Malicious site blocking
Two-Way IPS
VPN
Instant Guard
VPN Client L2TP
VPN Client OVPN
VPN Client PPTP
VPN Client WireGuard
VPN Server IPSec
VPN Server OVPN
VPN Server PPTP
VPN Server WireGuard
VPN Fusion
Support Surfshark
網路流量控制
Adaptive QoS
Bandwidth Monitor
Bandwidth limiter
--- Maximum Bandwidth Limiter Rule : 32
Traditional QoS
Traffic Monitor
Real-time traffic monitor
Wired Traffic Monitor
Wireless Traffic Monitor
Traffic Analyzer
• Traffic Analysis Period : Daily, Weekly, Monthly
Website history
WAN
Internet Connection Type :
• PPPoE
• PPTP
• L2TP
• Automatic IP
• Static IP
• IPSec
Dual WAN
3G/4G LTE dongle
4G / 5G Auto Mobile Tethering
Port forwarding
• Maximum Port Forwarding Rule : 64
Port triggering
• Maximum Port Triggering Rule : 32
DMZ
DDNS
NAT Passthrough :
• PPTP Pass-Through
• L2TP Pass-Through
• IPSec Pass-Through
• RTSP Pass-Through
• H.323 Pass-Through
• SIP Pass-Through
• PPPoE Relay
LAN
DHCP Server
有
IPTV
Manually assign IP address
• Maximum Manually Assign IP Address Rule : 128
Wake on LAN (WOL)
其他無線功能
UTF-8 SSID
WiFi MAC address filter
• Maximum MAC Filters : 64
Wireless scheduler
Airtime fairness
RADIUS Server
Universal beamforming
Explicit beamforming
USB埠應用
4G / 5G Auto Mobile Tethering
File System :
• HFS+
• NTFS
• vFAT
• ext2
• ext3
• ext4
Safely Remove disk
Download master
Media Server
Time Machine
Samba Server
FTP Server
Shared Folder privileges
User Interface
WEB: ASUSWRT
APP: ASUS Router APP
管理功能
Configuration backup and restore
Diagnosis tools
Feedback system
System log
New Device Connect Notification
Login Captcha
Connection Diagnosis
Auto Firmware Update
巴比祿 WCR-G300 無線寬頻分享器的詳細規格:
無線網路規格
無線標準: 支援 IEEE 802.11n、IEEE 802.11g、IEEE 802.11b。
傳輸速度: 最高達 300 Mbps (in 802.11n 模式)。
頻段: 僅支援 2.4 GHz 單頻。
天線: 外接 5dBi 高增益可調式天線兩支 (2x2)。
無線安全性: 支援 WPA2-PSK (AES, TKIP), WPA-PSK (AES, TKIP), WEP (128/64-bit).
有線網路與硬體介面
有線標準: 支援 IEEE 802.3/3u.
速度與流量控制: 10/100 Mbps (自動偵測).
連接埠數量:
WAN (網際網路) 埠: 1 x RJ-45 (Auto MDIX)
LAN (區域網路) 埠: 4 x RJ-45 (Auto MDIX)
USB 埠: 無.
其他功能與尺寸
設定介面: 網頁式引導安裝設計,介面簡單易用。
獨家技術:
AOSS™: Buffalo 獨家的一鍵安全連線系統,簡化裝置連線.
WDS: 支援無線橋接,可擴展訊號覆蓋範圍.
QoS: 支援頻寬管理.
ECO 節能: 具備省電功能,可設定關閉無線或有線網路以降低功耗.
