Description & features
LAUNCHXL-F28069M is a low cost evaluation and development tool for the F2806x [ https://www.ti.com/microcontrollers/c2000-real-time-control-mcus/products.html#p62=90;90 ] series as well as the InstaSPIN-FOC [ https://www.ti.com/instaspin-foc ] and InstaSPIN-MOTION [ https://www.ti.com/instaspin-motion ] enabled F2806x [ https://www.ti.com/microcontrollers/c2000-real-time-control-mcus/applications/instaspin.html ] series in the TI MCU LaunchPad ecosystem [ https://www.ti.com/microcontrollers/c2000-real-time-control-mcus/design-development.html#launchpads ] which is compatible with various plug-on BoosterPacks (suggested under the Recommended BoosterPacks in the Features section below). This extended version of the LaunchPad supports the connection of two BoosterPacks. The LaunchPad provides a standardized and easy to use platform to use while developing your next application.
Features
- USB connected isolated XDS100v2 JTAG debug probe for real-time debug and flash programming
- 4x 20-pin headers/connectors
- Programmable buttons and LEDs
- TMS320F28069M [ https://www.ti.com/product/TMS320f28069m ] : 90 MHz C28x CPU, 256 KB Flash, InstaSPIN-FOC and InstaSPIN-MOTION enabled, 12-bit ADC, CAN, 2x encoder interface (eQEP), UART, SPI, and more
- Supports two BoosterPacks
- Two encoder interface connectors
- Isolated CAN transceiver connector
- Hardware Files are in C2000Ware at boards\LaunchPads\LAUNCHXL_F28069M
- Free download of Code Composer Studio IDE [ https://www.ti.com/tool/ccstudio-c2000 ]
- Free download of MotorWare [ https://www.ti.com/tool/motorware ] for InstaSPIN-FOC and InstaSPIN-MOTION example projects
- Free download of controlSUITE [ https://www.ti.com/tool/controlsuite ] [and C2000Ware [ https://www.ti.com/tool/c2000ware ] ] for device drivers and example projects
- MathWorks Embedded Target Support [ https://www.mathworks.com/hardware-support/ti-c2000-piccolo.html ]
- Training video [ http://www.mathworks.com/matlabcentral/fileexchange/49109-dual-motor-control-with-ti-f28069-launchpad ] : two motors using LAUNCHXL-F28069M and two BOOSTXL-DRV8301
- solidThinking Embed Support [ http://www.solidthinking.com/embed_land_2017.html ]
- Training Video [ http://learn.solidthinking.com/embed-videos/pmsm-series/ ] : PMSM control series, including InstaSPIN-FOC
- Powersim PSIM Support [ https://powersimtech.com/applications/sensorless-pmsm-drive-instaspin/ ]
- InstaSPIN Processor-in-the-Loop [ https://powersimtech.com/instaspin-pil-feature/ ] (PIL) and code generation feature
- BOOSTXL-DRV8301 [ https://www.ti.com/tool/boostxl-drv8301 ]
- BOOSTXL-DRV8305EVM [ https://www.ti.com/tool/boostxl-drv8305evm ]
- BOOSTXL-BUCKCONV [ https://www.ti.com/tool/boostxl-buckconv ]
- TI BoosterPack Checker [ https://dev.ti.com/bpchecker/#/ ] for an interactive list of compatible BoosterPacks
What's included
- Piccolo F28069M Launchpad
- Mini USB Cable
- Quick Start Guide [ http://www.ti.com/lit/pdf/sprui02 ]
