詳盡技術資料請見原廠或供應商
https://store-usa.arduino.cc/products/arduino-nano-rp2040-connect-with-headers?selectedStore=us 料號:ABX00053(銲針腳) / ABX00052(不銲針腳)
***我們都是銷售國際大廠原裝產品,品質都相當優良可靠。不過為了避免不必要的紛爭,對於高單價產品我們有提供測試登錄序號的服務,確保產品出貨時是可以開機通訊的狀態,因此選購本商品我們將會拆封測試並提供基礎測試報告,若不能接受拆拆封測試者請勿下標,感謝您的配合。
PRODUCT DETAILS
Key Features
- **Raspberry Pi RP2040 Microcontroller:** The all-new low-cost Raspberry Pi silicon is the first microcontroller developed by the Raspberry Pi Foundation.
- **Dual-Core 32-bit Arm® Cortex®-M0+:** Get started with machine learning with TinyML, TensorFlow Lite or Edge Impulse thanks to the high-performance energy-efficient microprocessor clocked at 133 MHz.
- **U-blox® Nina W102:** The first and only RP2040 board with native Bluetooth and WiFi connectivity.
- **ST LSM6DSOX 6-axis IMU:** Combined accelerometer and gyroscope with a dedicated machine learning core.
- **Microchip ATECC608A Cryptographic Co-processor:** The powerful, low-power processor that is used in all MKR Family boards.
- **Step down converter:** Achieve high efficiency and low noise over a wide input voltage range with the built-in switch mode power supply
- **Arduino Nano Form Factor:** Solder headers to start prototyping with a breadboard, then solder directly into your final product. The familiar Nano form factor gives you the choice to use the board according to your needs, backed by the vibrant Arduino community.
Specification
| Board | Name | Arduino® Nano RP2040 Connect |
| ---- | ---- | ---- |
| SKU | ABX00053 |
| Microcontroller | Raspberry Pi RP2040 |
| USB connector | Micro USB |
| Pins | Built-in LED Pin | 13 |
| Digital I/O Pins | 20 |
| Analog input pins | 8 |
| PWM pins | 20 (except A6, A7) |
| External interrupts | 20 (except A6, A7) |
| Connectivity | Wi-Fi | Nina W102 uBlox module |
| Bluetooth | Nina W102 uBlox module |
| Secure element | ATECC608A-MAHDA-T Crypto IC |
| Sensors | IMU | LSM6DSOXTR (6-axis) |
| Microphone | MP34DT05 |
| Communication | UART | Yes |
| I2C | Yes |
| SPI | Yes |
| Power | Circuit operating voltage | 3.3V |
| Input voltage (VIN) | 5-21V |
| DC Current per I/O Pin | 4 mA |
| Clock speed | Processor | 133 MHz |
| Memory | AT25SF128A-MHB-T | 16MB Flash IC |
| Nina W102 uBlox module | 448 KB ROM, 520KB SRAM, 16MB Flash |
| Dimensions | Weight | 6 g |
| Width | 18 mm |
| Length | 45 mm |
Compatibility
- Software&Cloud
- Arduino IDE
- Arduino CLI
- IoT Cloud
- Web Editor
