MSI 微星 SPATIUM M480 PRO PCIe 4.0 NVMe M.2 1TB/2TB SSD 固態硬碟 /

✅產品特點

PCIe Gen 4x4介面和NVMe 1.4標準，可向下相容PCIe Gen 3/Gen 2/Gen 1

最高可達7400MB/秒之連續讀取速度和7000MB/秒之連續寫入速度。

Up 3000 TBW

支援全方位的資料安全性和糾錯功能

1TB to 4TB capacities in M.2 2280 form factor

適用於桌上型電腦及筆記型電腦

✅產品規格

Model Name SPATIUM M480 PRO PCIe 4.0 NVMe M.2

Capacity 1TB 2TB 4TB

Controller PHISON E18

Flash Memory 3D NAND

DRAM Cache 1GB DDR4 2GB DDR4 2GB DDR4

Form Factor M.2 2280

Interface PCIe Gen4 x4, NVMe 1.4

Compatibility PCIe Gen4 / Gen3 / Gen2 / Gen1

Dimensions 80.00mm (L) x 22.00mm (W) x 2.15mm (H)

Sequential Read up to

(MB/s) 7400

Sequential Write up to

(MB/s) 6000 7000 7000

Random Read 4KB up to

(IOPS) 750,000 1,000,000 1,000,000

Random Write 4KB up to

(IOPS) 1,000,000

Maximum Operating Power

(W) 9.5 10.5 11.3

Idle Power PS3 (mW) 40 45 50

Low Power L1.2 (mW) 3

Operating Temperatures 0°C – 70°C

Storage Temperatures -40°C – 85°C

Terabytes Written (TBW) 700 1400 3000

Mean Time Between Failure

(MTBF) Up to 1,600,000 Hours

Limited Warranty 5 Years, or the coverage for the maximum

TBW as stated, whichever comes first.

Advanced Features

TRIM (Performance Optimization, OS Support

required)

SMART (Self-Monitoring, Analysis and

Reporting Technology)

LDPC (Low Density Parity Check) ECC

Algorithm

End to End Data Path Protection

APST (Autonomous Power State Transition)

AES256/Pyrite (Encryption, Data Security)
